3m Cable Jointing Kit Catalogue

Cable joints and terminations manufactured by 3m are used to repair damaged cables replace cable fault sections extend existing cable circuits and connect cable ends for termination onto electrical equipment bushings in switchgear and transformers including 11kv and 33kv power cables operating at medium high voltages.

3m cable jointing kit catalogue.

3m electrical cold shrink scotchcast. The joints are available for 11 22 33 kv. 3m has an ongoing commitment to research and development. 3m developed cold shrink more than 25 years ago.

3m developed electrical insulating pvc tape. The kit provides a lightweight compact and environmentally sealed system for splicing extruded dielectric shielded power cables. Cable joints cable jointing resins. It is a safer reliable and easy to install solution for medium voltage jointing and terminating.

Cable joints terminations. The components of the kit are designed for conditions where the terminations are exposed to rainfall outdoor sunlight extremes of weather and heavily polluted areas. The terminations are available for 11 22 33 kv. Jointing kit resin volume cable diameter cc max min la21 173 26 8 la22 400 32 14 la23 673 37 23 la24 1164 51 28 la25 2909 60 33 la26 6364 80 48 la27 9545 90 45 3m la inline joint 3m la transition joint supplementary kits for transition and paper cable jointing use one supplementary kit for a transition joint and two for a paper to paper.

Resin cable joints are suitable for low voltage jointing of cables with xlpe epr pvc or pilc insulation 1 5 400sqmm 600 1000v up to 3 3kv t d stock and distribute the most complete range of cable joints. 3m has over 50 years experience in electrical products and processes.
